HDG And Bark Artificial Tree Cell Towers Palm Tree Monopole Tower 0-200m Height
Product Summary
Artificial palm tree monopole tower The leaves quantity and AMB arrangement and height as per client requests or we can come up with our experience. We have long-term compatible partner to offer the leaves passing the wind speed up to 290km/hr. 3 grain barks avaiable. 1 Design standard ANSI-TIA/EIA...
Basic Properties
Place of Origin:
China
Brand Name:
HL
Certification:
ISO, CE
Model Number:
HL-022
Trading Properties
Minimum Order Quantity:
1 set
Price:
USD 5,000-40,000/Set
Payment Terms:
L/C, T/T
Supply Ability:
Seaworthy packing or as per client request
Product Description
Artificial palm tree monopole tower
The leaves quantity and AMB arrangement and height as per client requests
or we can come up with our experience.
We have long-term compatible partner to offer the leaves passing the wind speed up to 290km/hr.
3 grain barks avaiable.
| 1 | Design standard | ANSI-TIA/EIA-222G, H or Euro and Australia, South Africa,etc |
| 2 | Design parameters | Design wind speed, operational wind speed, EPA or FPA, structrue class, topographic class, deflection degree |
| 3 | Welding standard | AWS D1.1 or China state grid 10k voltage transmission line standard |
| 4 | HDG standard | ASTM A123 or ISO 1461 |
| 5 | Bolt standard | ISO 898 Gr. 6.8 or 8.8 or 10.9 |
| 6 | Steel grade | GBT Q355, Q235, ASTM A572 gr.50, ASTM A36 or S355JR, S235JR |
| 7 | Foundation design | 50kpa, 100kpa, 150kpa,etc |
| 8 | Tower type |
1. Angular tower in 3 legs or 4 legs 2. Tubular tower in 3 legs or 4 legs 3. Camouflaged palm/pine/coconut tree tower 4. RDS tower 5. Guyed mast 6. Monopole 7. Rooftop pole tower 8. Street lightning pole 9. Cell on wheel 10. Electric transmission line towers 11. Substation gantry 12. Other steel structrues |
| 9 | Warranty | 15 years-30 years |
| 10 | In house QC control | Raw material, size, welding, HDG, assembly and packing all will submit report for free. |
| 11 | After-sales local offices | In Africa, Southeast Asia, Latin America, Canada, Australia. Specific details contact us |
| 12 | Accessories | Paint, AWL, earthing/grounding material, fence, fall arrest system,etc |
Product Details
Highlight:
Artificial monopole tower
,palm tree monopole tower
,Monopole artificial tree cell towers
Type:
HDG Monopole With Treated Bark And Leaves
Material:
GB Q235 Or Q355
Surface Treatment:
HDG And Bark
Advanced Equipment:
2,400 Tons Press Machine And Laser Cutting Machine, Auto Walding Machines
Height:
0-200m
Warranty:
15 Years
Port:
Qingdao
