Q345 Steel Supporting Traffic Sign Poles Powder PVDF Coating

  • Q345 Steel Supporting Traffic Sign Poles Powder PVDF Coating
  • Q345 Steel Supporting Traffic Sign Poles Powder PVDF Coating
Place of Origin Guangzhou, China
Brand Name GUANGXIN
Certification ISO9001
Model Number TSP-003
Minimum Order Quantity 10 sets
Price USD198-2038 per piece
Packaging Details Plastic bubble sheets and belts
Delivery Time 20-30 days
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 5000 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Traffic Sign Poles Material Non-alloy Structural Carbon Steel
Design Self-supporting Pole With Single Or Multiple Arms Height 4m To 20m
Steel Grade Q235, Q345 Or Specified Steels Yield Strength Not Less Than 235MPa
Dimensions Customized To Requests Application Street Roadways, Highways And Toll Gates
High Light

Q345 Traffic Sign Poles

,

PVDF Traffic Sign Poles

,

Q345 street sign post
Leave a Message
Product Description

Q345 Steel Supporting Traffic Sign Poles Powder PVDF Coating



Traffic Signboard Steel Supporting Pole Or Tower



1, Foundations with anchoring bolts frames

2, Lattice Tower sections

3, Connecting plates

4, Platforms (1-5 platforms)

5, Brackets for mountning antennas and other communication facilities.



1, Steel Communication and Power Transomission and Distribution Lattice Towers

2, Steel Communication and Power Transomission and Distribution Lattice Poles

3, Street Light Poles

4, Traffic Signal Lights and Monitor Cameras Steel Poles and gantries.

5, Artificial Trees for landscaping and camouflaged communication towers.

6, Other structural steel frames etc.





Specifications



Descriptions Steel poles for mounting lights, CCTV camera, signboards, billboards, LED screen etc.
HS Code 7308900000
Material Low carbon weldable structural steel
Grade GB Q235, Q345, BS4360, ASTM A36 etc.
Yield Strength 235-355MPa
Height 5m to 35m or other specified height
Thickness 4mm to 15mm, depending on height of pole.
Pole Shape Conical/tapered, straight round/cylindrical, square or rectangular, polygonal etc.
Diameter or Dimensions Subject to height of pole and required mechanical properties.
Design Single, dual or multiple straight or curved arms and brackets
Surface Finish Hot dip galvanization plus powder or PVDF coating (optional)
Galvanization 65-100 Microns
Coating 35-80 Microns
Color Silver, grey, black, white, blue, yellow etc.
Applications Roadways, streets, highways, stadiums, public sqaures, airports, railway stations, communities, parking lots, gardens etc.



The popular steel light poles include tubular steel pole, solar street light pole, conical or tapered light pole, hexagonal or polygonal lighting pole, straight round street light pole and octagonal lighting pole. There are 2 ways of installation of the steel poles, one is directly buried and the other way is fixed to steel frame foundation with anchor bolts by base plate with bolts and nuts.





                                                  All in 1 integrated Traffic Signal Light Pole



Features



1, Custom designs

2, Easy installation and mounting

3, Multi-functional applications

4, Steady and  high wind load.

5, Flexible heights and dimensions

6, Popular for traffic signal and safety management as well as utility lighting and smart city systems.
