Weldable structural 20-100m Transmission Steel Tower 3 Or 4 Legged Lattice Tower

Place of Origin China
Brand Name Guangxin
Certification ISO9001
Minimum Order Quantity 1 set
Price USD1.28 to USD1.68 per kilogram
Packaging Details bundles
Delivery Time 20-40 days
Payment Terms T/T, L/C, Western Union, MoneyGram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Tower Type 3 Or 4 Legs Self-supporting Lattice Tower Material Weldable Structural Low Carbon Mild Steel
Quality Standard GB/T2694-2010 Installation Method Bolting
Design Life 50 Years Weight As Per Tower Height
Foundation Type Steel Framed Pile Foundation, Anchor Foundation Galvanization Hot-dip Galvanization
High Light

Weldable Structural 100m Transmission Steel Tower


4 Legged Transmission Steel Tower


3 Legged Lattice Tower

Leave a Message
Product Description

20-100m Transmission Steel Tower 3-Legged Or 4-Legged Lattice Tower

Product Description:

Galvanized Steel Self-supporting Transmission Steel Tower

Our transmission steel tower is a 3-legged or 4-legged lattice tower designed for power transmission and distribution, radio or TV broadcasting and other communication sigal covering applications, and is built to the highest quality standards according to GB/T2694-2010. It is suitable for use in a wide range of outdoor environments, with a temperature range of -40℃ to +50℃. The tower's height can range from 20 to 100 meters, with its weight adjusted accordingly. It is installed on either pile foundation or anchor foundation.

Weldable structural 20-100m Transmission Steel Tower 3 Or 4 Legged Lattice Tower 0


  • Product Name: Transmission Steel Tower
  • Design Life: 50 Years
  • Tower Type: Tubular steel Tower, Angle steel Tower, Hybrid Tower
  • Foundation Type: steel framed concrete Pile Foundation, Anchor Foundation
  • Surface Treatment: hot dip galvanization
  • Galvanization thickness: 55-110 Microns
  • Light Duty or Heavy Duty Tower
  • Triangle or Square Section or polygonal towers optionally.
  • Made from Weldable structural tubular Steel or Angle Steel.

Technical Parameters:

Parameter Value
Surface Treatment hot dipped galvanization
Connection Bolted Connection
Foundation Type steel framed concrete Pile Foundation, Anchor Foundation
Height 20-100m
Design Wind Speed 50-160km/h
Design Life 50 Years
Weight As Per Tower Height
Galvanization caoting thickness 55-110um according to steel thickness
Welding CO2 Welding
Quality Standard GB/T2694-2010
Application Radio Broadcasting, TV broadcasting, GSM Telecom covering, power transmission etc.


Guangxin is a leading brand in Transmission Steel Tower, which is mainly used in greenfield tower for various applications such as TV broadcasting. Guangxin Transmission Steel Tower is designed to withstand wind speed from 50-160km/h, and its foundation type includes pile foundation and anchor foundation. We offer tower section in triangle or square shape and various types of tower such as tubular tower, angle tower and hybrid tower. All the towers are made of premium quality steel and have been through sand blasting and galvanized anti-corrosion process.



Guangxin Transmission Steel Tower

Brand Name: Guangxin

Place of Origin: China

Quality Standard: GB/T2694-2010

Tower Type: Tubular Tower, Angle Tower, Hybrid Tower

Weight: As Per Tower Height

Welding: CO2 Welding

Material: Mild Steel

Guangxin has been a leading manufacturer and supplier of transmission tower, light duty or heavy duty tower, telecom tower, substation structure, etc. for many years. Our transmission steel tower is made of high quality mild steel and is welded with CO2 welding. The weight of the tower is based on the tower height and it is certified with GB/T2694-2010. We offer various types of towers including tubular towers, angle towers, and hybrid towers. We guarantee superior quality and performance of our transmission steel tower.

Weldable structural 20-100m Transmission Steel Tower 3 Or 4 Legged Lattice Tower 1

Support and Services:

We provide technical support and services for Transmission Steel Tower. Our services include:

  • Design and engineering services, including structural analysis, foundation design, and civil engineering.
  • On-site installation and commissioning.
  • Service and repair.
  • Training and user support.
  • Long-term maintenance.


Q: What is "Transmission Steel Tower"?
A: "Transmission Steel Tower" is a steel tower manufactured by Guangxin, a Chinese brand. It is used to carry and support overhead power lines.
Q: What are the features of Transmission Steel Tower?
A: Transmission Steel Tower has features such as high strength, light weight, corrosion resistance, low cost and long service life.
Q: What types of Transmission Steel Tower are available?
A: Guangxin offers various types of Transmission Steel Tower, such as angle steel tower, steel structure tower, tubular tower, and lattice tower.
Q: What is the application of Transmission Steel Tower?
A: Transmission Steel Tower is mainly used for transmission line projects, such as power transmission lines, communication lines, and broadcast lines.
Q: What is the production process of Transmission Steel Tower?
A: The production process of Transmission Steel Tower includes cutting, welding, surface treatment, assembly, and testing.
