50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM

  • 50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM
  • 50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM
  • 50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM
  • 50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM
  • 50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM
Place of Origin Guangzhou, China
Brand Name GUANGXIN
Certification ISO9001
Model Number GWT-005
Minimum Order Quantity 1 set
Price USD1998-9998 per set
Packaging Details bulk
Delivery Time 20-30 days
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 500 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 3 Leg Tower Material Weldable Structural Angle Steel Plates And Pipes Or Round Bars
Height 15m-50m Design Telescopic Mast Guyed Wire Tower
Wind Load 0.35-0.85kN/sqm Applications Communication Telecom Antenna Transmission
High Light

50m Guyed Wire Towers

,

OEM Guyed Wire Towers

,

50m 3 leg tower
Leave a Message
Product Description

50m High Mast Guyed Wire Towers 3 Legged Galvanized Steel OEM



50m High Mast Guyed Wire Telecommunication Antenna Tower





Features



* Telescopic mast tower to match required heights.

* Custom designs and precise fabrication.

* Popular for Movable mobile communication transmission atenna station

* 3 or 4 legs lattice tower designs, flexible height from 10m to 70m.

* Motorized tower, easy for installation, transportation and moving.





Specifications



Material Tubular steel pipes, angular steel plates, flat steel plate or solid steel bars, bolts and nuts
Steel Type Weldable low carbon structural steel
Steel Grade GB Q235, Q345, BS 4360, ASTM A36 etc.
Yield Strength Fy≥235MPa
Tensile Strength Fu≥400MPa
Elongation σ≥20%
Surface Finish Hot dip galvanization
Galvanized layer T≥65μm
Height 20m to 100m, customized to requests
Design 3 legs self-supporting or free standing lattice tower
Structure 1 to 5 platforms, each platform comes with 4 to 6 brackets for mounting antennas or specified number of brackets for mounting antennas, microwaves, RRUs and other devices.
Supply mode CKD(Complete Knocked Down), SKD(Semi-Knocked Down), DKD(Direct Knocked Down)
Fixing/Fastening Bolts and nuts, connecting flanges
Configuration Foundations/anchoring bolts, tower sections, 1-5 platforms (optional), mounting brackets, ladder, anti-fall safety system, lightning rod, earthing plate etc.
Wind Load 0.35-1.0kN/sqm
Lifespan 20-50 years
Warranty 3 years
Applications GSM/3G/4G/5G/FM radio antennas, microwaves, telecom stations



Self-supporting steel communication tower

4 legged angular lattice tower made up of galvanized steel flat plates and angle steel plates

FM radio transmission tower, GSM 3G, 4G, 5G communication microwave and antenna tower
