ODM Galvanised Street Light Pole Octagonal Steel Post 3mm Thickness

  • ODM Galvanised Street Light Pole Octagonal Steel Post 3mm Thickness
Place of Origin Guangzhou, China
Brand Name GUANGXIN
Certification ISO9001
Model Number GX-1328
Minimum Order Quantity 100pcs
Price USD40-80 per piece
Packaging Details air bubble sheet package
Delivery Time 20-30 days
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 2000 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Electrical Steel Power Poles Welding Method CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
Ground Mounted The Length Buried Underground As Per Customers Requirement Galvanizing Hot Dip Galvanization With Thickness Of 80-100µm Average
Surface Finish Hot Dip Galvanization Plus Powder Coating(optional) Shape Octagonal Tapered Conical
Ice Coating 5mm-10mm(different In Different Regions) Work Life More Than 10years
High Light

ODM Galvanised Street Light Pole

,

3mm Thickness Galvanised Street Light Pole

,

5mm Galvanised Street Light Pole
Leave a Message
Product Description

Customized ODM Octagonal Steel Post 3mm Thickness







Specification of Octagonal Steel Post:



Descriptions Octagonal Steel Pole for Electric Power Transmission, CCTV Camera, LED light
Material Low carbon weldable structural steel
Grade GB Q235, Q345, BS4360, ASTM A36 etc.
Yield Strength 235-355MPa
Height m to 12m or other specified height
Thickness 4mm to 15mm, depending on height of pole.
Pole Shape Conical/tapered, straight round/cylindrical, square or rectangular, polygonal etc.
Diameter or Dimensions Subject to height of pole and required mechanical properties.
Design Single, dual or multiple straight or curved arms and brackets
Surface Finish Hot dip galvanization plus powder or PVDF coating (optional)
Galvanization 65-100 Microns
Coating 35-80 Microns
Color Silver, grey, black, white, blue, yellow etc.
Applications Roadways, streets, highways, stadiums, public sqaures, airports, railway stations, communities, parking lots, gardens etc.





Feature of Octagonal Steel Post:

1. Material: Q235, Q345 steel

2. Mounting Height: 3-20M, Thickness: 3-12mm

3. Brackets: Single or double brackets are in the shape and dimension as per customers requirement

4.Welding: Welding confirms with international welding standard of CWB

5. Galvanizing: Hot dip galvanization with thickness of 80-100µm average

6. There are 2 ways of installation of the steel poles, one is directly buried and the other way is fixed by base plate with bolts and nuts.

7. Base plate mounted: Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement
Ground mounted: The length buried underground as per customers requirement
