5m Height Galvanized Street Light Pole Grey Color Painting

  • 5m Height Galvanized Street Light Pole Grey Color Painting
Place of Origin Guangzhou, China
Brand Name GUANGXIN
Certification ISO9001
Model Number GX-1306
Minimum Order Quantity 100pcs
Price USD40-80 per piece
Packaging Details air bubble sheet package
Delivery Time 20-30 days
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 2000 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 5m Height Galvanized Street Light Pole Grey Color Painting Galvanization Standard ASTM A123/ ISO 1461
Surface Finish Hot Dip Galvanization Plus Powder Coating(optional) Height 5-10m
Welding Method CO2 Shielded Arc Welding & Submerged Arc Welding(SAW) Welding Standard AWS D1.1
Color Grey Color Painting Pole Shape Conical, Tapered, Octangular, Polygonal, Round Etc.
Arms 1 Arms Or Customized ODM Applications Traffic Monitor, Public Security CCTV, Parking Lotsurveillance Etc.
High Light

5m Height street lamp pole

,

5m Decorative Street Light Pole

,

ODM Garden Street Light Pole
Leave a Message
Product Description

5m Height Galvanized Street Light Pole Grey Color Painting



Specification:

Descriptions Steel poles for mounting lights, CCTV camera, guideboards, billboards etc. Double Arm Street Light Pole
Material Low carbon weldable structural steel
Grade GB Q235, Q345, BS4360, ASTM A36 etc.
Yield Strength 235-355MPa
Height 5m to 12m or other specified height
Thickness 4mm to 15mm, depending on height of pole.
Pole Shape Conical/tapered, straight round/cylindrical, square or rectangular, polygonal etc.
Diameter or Dimensions Subject to height of pole and required mechanical properties.
Design Single, dual or multiple straight or curved arms and brackets
Surface Finish Hot dip galvanization plus powder or PVDF coating (optional)
Galvanization 65-100 Microns
Coating 35-80 Microns
Color Silver, grey, black, white, blue, yellow etc.
Applications Roadways, streets, highways, stadiums, public sqaures, airports, railway stations, communities, parking lots, gardens etc.



The Pole is made of high quality material steel Q235 and the weld is smooth. Galvanization by inside and outside hot dip galvanizing. 15 years no rust.



It is widely used in new rural roads, urban arterial roads or slow lane, branch roads, and road lighting in public places such as scenic spots, parking lots, parks, squares and other public places.



The popular steel light poles include tubular steel pole, solar street light pole, conical or tapered light pole, hexagonal or polygonal lighting pole, straight round street light pole and octagonal lighting pole. There are 2 ways of installation of the steel poles, one is directly buried and the other way is fixed by base plate with bolts and nuts.



Typical installation way of steel poles, especially for the high mast lighting or communication poles



Hot dip galvanization with thickness of 80-100µm average in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123, IS: 2626-1985



Manufacturing technology:The light pole is formed integrally with smooth line,treated with internal and external hot galvanizing.The process of galvanizing is acid washing,hot galvanizing,washing,passivation and so on.Conforms to the national standard GB/T13912-92.Zinc plating adhesion,conforms to the standard GB2694-88 request,the anticorrosion life is more than 30 years.


Directly buried light post

5m Height Galvanized Street Light Pole Grey Color Painting 0


Applicable Examples of Steel Poles
5m Height Galvanized Street Light Pole Grey Color Painting 1




6m x 10m (6m high pole 10m long arm) Galvanized Steel Traffic Sign, Camera and Signal Light Cantilever

5m Height Galvanized Street Light Pole Grey Color Painting 2
Billboard and Sign Galvanised Steel Support Column and Gantry Frame
