3 Legs Tripod Steel Rooftop Antenna Tower 15M Self Supporting Explosion Proof
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | GUANGXIN |
| Certification | ISO9001 |
| Model Number | RTT-023 |
| Minimum Order Quantity | 1 set |
| Price | USD198-2038 per piece |
| Packaging Details | wooden pallet and cartons |
| Delivery Time | 20-30 days |
| Payment Terms | T/T, L/C, Western Union, MoneyGram |
| Supply Ability | 1000 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Rooftop Mast | Material | Weldable Structural Steel Pipes And Plates |
|---|---|---|---|
| Surface Finish | Hot Dip Galvanization | Height | 5m To 20m |
| Design | Climbable Bipod Tower With Mounting Brackets | Lifspan | 20-50 Years |
| Warranty | 3 Years | Delivery Time | 20-30 Days |
| Applications | Communication Antenna Stations, TV Signal Transmission | ||
| High Light | BS 4360 Rooftop Antenna Tower,15M Rooftop Antenna Tower,15M rooftop mast |
||
Product Description
3 Legs Tripod Steel Rooftop Antenna Tower 15M Self Supporting Explosion Proof
Galvanized Steel Bipod Tripod And Lattice Rooftop Communication Antenna Tower
Galvanized Steel Tripod Rooftop Antenna Tower
Specifications
| Material | Steel pipe/tubes, Angle steel plates, flat steel plates, bolts and nuts rooftop mast |
| Steel Type | Weldable low carbon structural steel |
| Steel Grade | GB Q235, Q345, BS 4360, ASTM A36 etc. |
| Yield Strength | Fy≥235MPa |
| Tensile Strength | Fu≥400MPa |
| Elongation | σ≥20% |
| Surface Finish | Hot dip galvanization |
| Galvanized layer | T≥65μm |
| Height | 5m to 20m, customized to requests |
| Design | 3 legs bipod, tripod self-supporting or free standing lattice tower |
| Structure | 1 to 2 platforms, each platform comes with 4 to 6 brackets for mounting antennas or specified number of brackets for mounting antennas, microwaves, RRUs and other devices. |
| Supply mode | CKD(Complete Knocked Down), SKD(Semi-Knocked Down), DKD(Direct Knocked Down) |
| Fixing/Fastening | Bolts and nuts, connecting plates |
| Configuration | Foundations/anchoring bolts, tower sections, 1-2 platforms (optional), mounting brackets, ladder or steps, anti-fall safety system, lightning rod, earthing plate etc. |
| Wind Load | 0.35-1.0kN/sqm |
| Lifespan | 20-50 years |
| Warranty | 3 years |
| Applications | GSM/3G/4G/5G/FM radio antennas, microwaves, telecom stations, TV signal transmission. |
How long can you deliver?
15-35 days after confirming shop drawings, depending on order quantity.
What’s your advantages comparing with other suppliers?
We have been specializing in this field for more than 10 years since 2009, we have professional engineers and designers, skilled workers, advanced production line equipped with CNC and laser cutting machines, welding machines, shaping machines, test instruments etc., we can produce the poles and towers or other steel frameworks according to customers’ designs, specifications, drawings, requirements. Our quality is very good but price is reasonable and competitive. We’re also providing excellent in-sales and after-sales services. We always provide good quality products and services beyond customers’ expectations.
Can I customize the towers, poles or frameworks?
Yes, we can fabricate the towers, poles, frameworks or other related products according to your drawings, specifications and requirements.
What’s your payment terms?
T/T or irrevocable documentary L/C is accepted for us. The general payment arrangement is 30% down payment before production and full payment before shipping by T/T, or L/C issued before production.
Can you guarantee the quality?
Yes.
Where are you shipping?
We usually ship from any port of Guangzhou or Shenzhen, other ports in other cities are also available if required.
